Advanced Pilot Valve
Advanced pilot valves (APVs) are used in the PRV control solution, which is used to remotely control pressure, or automatically deliver target pressures at a critical point. It operates on all globe type diaphragm actuated pressure reducing valves (PRVs) greater than 50mm.
Features:
- Linear pressure/position relationship
- Absolute pressure adjustment
- Pilot position indicator
- Selection of mounting options
- Position feedback to control logger
- Upstream, downstream and control space connections ⅜” bsp (f)
- IP68 connector to i2O controller
- Size (mm): w198 x d149 x h130
- Weight (kg): 5
- IP68 continuously submersible to 4m
- Operational temperature 1°C to +60°C
- Stainless steel (316) construction
- WRAS approved
